Waterproof rubber cable JHS is used to connect submersible motors with AC voltage of 300/500V and below. One end of the cable is in water and the working temperature is not more than 60 °C for a long time.
Product Description
Insulation: EPR(Ethylene Propylene Rubber)
Sheath: PCP(Polychioroprene)
Sheath Color: Black
Voltage: 450/750V
Temperature Rating: conductor operation temperature -30°C to +60°C(85°C max)
Minimum Bending Radius: Up to 25mm2,6xoverall diameter
Above to 25mm2,8xoverall diameter
|
Cores x mm2
|
Weight kg/km
|
O/D mm
|
|
3 G 1.0
|
111
|
8.9
|
|
4 G 1.0
|
134
|
9.7
|
|
1 x 1.5
|
48
|
5.9
|
|
1 x 1.5
|
48
|
5.9
|
|
2 x 1.5
|
109
|
8.7
|
|
3 G 1.5
|
137
|
9.7
|
|
4 G 1.5
|
169
|
10.7
|
|
5 G 1.5
|
206
|
11.6
|
|
7 G 1.5
|
371
|
16
|
|
12 G 1.5
|
546
|
20
|
|
19 G 1.5
|
777
|
23.5
|
|
27 G 1.5
|
1090
|
27.5
|
|
37 G 1.5
|
1300
|
31
|
|
1 x 2.5
|
62
|
6.5
|
|
2 x 2.5
|
162
|
10.6
|
|
3 G 2.5
|
198
|
11.4
|
JHS waterproof cable usage
Waterproof rubber sheathed cables are used for transmitting electrical energy on submersible motors with AC voltage of 500V and below.
JHS waterproof cable usage conditions
The long-term allowable working temperature of the cable is 65 ℃.
JHS waterproof cable specifications: number of cores x cross-sectional area/mm2, single core, three cores, four cores -3 x 2.5 3 x 2.5+1 x 1.5 1 x 4 3 x 4 3 x 4+1 x 2.5 1 x 6 3 x 6 3 x 6+1 x 4 1 x 10 3 x 10 3 x 10+1 x 6 1 x 16 3 x 16 3 x 16+1 x 6 1 x 25 3 x 25 3 x 25+1 x 6 1 x 35 3 x 35+1 x 6 1 x 50-1 x 70-
JHS waterproof cable insulation material: waterproof rubber is used for insulation; The filling of cables is also made of waterproof rubber; The cable sheath adopts waterproof rubber sheath, which is suitable for water treatment equipment such as submersible pumps, coal mines, underwater operations, and underwater scenic lights. This product uses high-density adhesive with waterproof and other functions.
